Main motor power |
7.5kw*2 |
notes |
|
Traveling motor power |
0.75kw |
|
|
Equipment voltage |
380v 50Hz |
customizable |
|
Thickness processing range |
0.8-100mm |
customizable |
|
Maximum machining widt |
1000mm |
Polishing length is not limited |
|
Belt size |
1620*1000mm*2 |
Can be equipped with a wire drawing roller |
|
Overall dimensions of the equipment |
1500*1400*1750mm |
Package size 1550*1420*1800mm |
|
Net weight of equipment |
850kg |
The gross weight should be 890KG |
|
lift platform |
Electric lifting |
|
|
Overall equipment control |
Panel mounted distribution box control, one click start |
