Disk Brush Type Deburring Machine

Name: Disk Brush Type Deburring Machine
Brand: www.xydpolishing.com
SKU: ATGS
Availability: InStock
Rating: 5 (1 reviews)

No.ATGS

ATGS series is a brush disk structure. A group of workstations isequipped with 7 to 9 brush disks. During processing, the brushdisks rotate on their own and swing left and right or rotate360° to deburr the surface of the workpiece.

Disk brushing: Deburrs the edges and holes of the workpieceso that the surface of the workpiece does not sag and allrhombus-edge holes achieve a uniform R-arc. Scope of appli-cation of the equipment: Suitable for precision stamping parts,gear parts, automotive parts, powder metallurgy parts,machined parts, etc.

Get A Quote

Add to Quote List View Quote List

SPECIFICATION

Product Function Introduction:

Abrasive Belt: Driven by high-speed grinding rollers, the abrasive belt performs brushing, polishing, slag removal, and oxide scale removal on the workpiece surface.
Disc Brush: Deburrs edges and holes of the workpiece, ensuring smooth, uniform edge rounding without collapsing the surface. All edges and holes achieve consistent R-radius finishing.

Application Scope:Suitable for precision stamped parts, gear components, automotive parts, powder metallurgy products, and machined parts.

Basic Technical Parameters:

Processing Widths: 400mm, 600mm, 800mm, 1000mm, 1300mm
Conveying Method: Conveyor belt + rubber pressure roller clamping conveyor
Worktable Adsorption Method:
Permanent Magnetic Adsorption (For workpieces ≥ 20mm x 20mm)
Vacuum Adsorption (For workpieces ≥ 50mm x 50mm)
Automatic Thickness Calibration:
Four-column synchronous lifting rod mechanism
Digital screen settings with automatic positioning for precise thickness control

This equipment delivers efficient and precise surface finishing, deburring, and edge rounding, enhancing the quality and performance of metal components across various industries.
